PALLET WRAPPER-SJ4550

SJ4550---Automatic crab Robot Pallet wrapping machine,stretch wrapper,Pallet wrapper

Auto/automatic pallet wrapping machine/stretch wrapper/stretch wrapping machine-Pre-stretch film carriage upto 250%, photocell detect pallet height, keyboard control panel

Mobile robot for wrapping in less than one minute palletized loads of any shape, weight and dimension with stretch film.



Specifications

Control System:Programmable

Min pallet size:600 x 600mm

Max pallet height:2100mm

Film reel inside diameter:75mm

Film reel outside diameter:250mm

Film-rack lift motor:0.18kw

Power supply:220V 50HZ 1Phase /380V 50HZ 3Phase

Machine weight :325kg



Parameters easily adjustable from the panel

*all function parameters on display

*Bottom pallet wrapping rounds from 0 -10

*Top pallet wrapping rounds from 0-10

*Photocell sensing externally adjustable

*Spool carriage up/downward speed adjustable from 1,3 a 5, 4 M/MIN

*4 separate wrapping cycles

*Double cycle (upward/downward)

*Single cycle (only upward or only downward)

*Fixed height of reinforcing wrapping rounds

*Manually adjustable wrap style



Features

* No pallet size limit

* Foldable mast

* One-man-install

* Move easily
